MITS 3D Printer Materials and Applications

When selecting 3D printers, “making full use of materials” is the key.
MITS 3D printer comes with support services based on our broad experiences.

For MITS 3D printer, two types of resins are available. Acrylic resin is good for mockup or functional
prototyping for Mechanical parts. Rubber like resin has flexibility and stretching properties.
Other than those two materials, conductive resin and lost form resin are available.

Acrylic resin for Flash75

With resins for MITS 3D printers, even first time users can print objects with less failure. Also MITS 3D printer resins are improved so that printed objects are less breakable. MITS 3D printers are environment friendly as resin is low viscosity and that can reduce the use of alcohol for cleaning object. Color: orange

Acrylic resin

Acrylic resin and Rubber like resin can be used individually or mixing two together with the ratio of your choice. So you can obtain own material with softness of your choice.

Rubber like resin

There are two types of rubber like resins, standard and Highly stretchable that stretches twice as normal rubber like resin. Color: clear (coloring can be done by user)

Other (M3DS-200, M3DS-300 only)

Conductive resin This material can be used for research for sensing devices that require conductivity. Conductive acrylic resin and conductive rubber like resin are available. volume resistivity : 1.64 x 10 Ωcm ~ color: black
Lost form resin This is used for master model for lost form. Color: red

Resin	Acrylic resin for Flash75	Acrylic resin	Rubber like resin / Highly stretchable rubber like resin	Conductive Acrylic resin / Conductive Rubber like resin	Lost form resin
Application	Prototyping for mechanical parts		Prototyping for elastic parts or product	Parts require conductivity	Prototyping for lost form master
color	Orange	Clear	Clear	Black	Red
Applicable 3D printers
FLASH 75	◎	◯	◯	✕	✕
M3DS-100	✕	◎	◎	✕	✕
M3DS-200	✕	◎	◎	◎	◎
M3DS-300	✕	◎	◎	◎	◎
